Industrial HRC50 Solid Carbide Flat End Mill (TiAlN Coated) – OEM Sizes
Premium 4-Flute General Purpose End Mill for Steel (HRC50) – Customizable
Quick Specifications
| Product Name | OEM HRC50 Solid Carbide Flat End Mill (TiAlN Coated) |
|---|---|
| Milling Cutter Type | 4-Flute Flat End Mill (Square End / General Purpose) |
| Material | Premium Solid Hard Alloy (Tungsten Steel) |
| Tool Hardness Rating | HRC50 |
| Coating | Advanced TiAlN (Titanium Aluminum Nitride) Coating |
| Flutes | 4 Flutes |
| Diameter Range | Standard D1.0 - D20.0mm (Fully Customizable to OEM Specs) |
| Overall Length | Standard 50mm - 100mm (Custom Lengths Supported) |
| Application | Stainless Steel, Carbon Steel, Cast Iron, Pre-Hardened Steel |
| Brand Name | Xiaoman Tools |
| Place of Origin | Shanghai, China |
| Customized Support | 100% OEM/ODM/OBM (Custom Dimensions, Laser Etching, Packaging) |
- Factory Direct Pricing
- Strict Standard QC
- Support OEM / Custom Packaging
Want to know the MOQ and latest price?
Product Details
Industrial HRC50 Solid Carbide Flat End Mill (TiAlN Coated)
The Essential, High-Reliability Workhorse for Everyday CNC Machining
Equip your wholesale catalog with the most highly demanded tool in the metalworking industry. Xiaoman Tools' HRC50 General Purpose Flat End Mills are engineered to deliver consistent, dependable performance across a wide spectrum of daily milling tasks. Forged from premium solid tungsten steel and protected by a robust TiAlN (Titanium Aluminum Nitride) coating, these 4-flute cutters provide excellent wear resistance when machining stainless steel, carbon steel, and cast iron. As a true manufacturing partner, we do not just sell off-the-shelf items; we offer comprehensive OEM solutions, allowing you to fully customize cutting diameters, flute lengths, and brand packaging to build your own tooling empire.
Key Technical Advantages
- Advanced TiAlN Coating: The Titanium Aluminum Nitride coating excels in general steel machining, forming a protective barrier that significantly reduces thermal shock and edge wear, effectively extending the tool's lifespan.
- HRC50 Universal Toughness: Carefully balanced for strength and durability, the HRC50 rating ensures reliable, chatter-free performance across the vast majority of standard workshop materials without the brittleness of ultra-hard cutters.
- High-Rigidity 4-Flute Geometry: The 4-flute square-end design maximizes the core diameter of the tool, providing immense rigidity and minimizing deflection during heavy side milling and slotting operations.
- Optimized Edge Sharpness: Precision-ground flutes guarantee rapid chip evacuation and a clean shearing action, resulting in excellent surface finishes on both ferrous and non-ferrous workpieces.
- 100% Unrestricted OEM Flexibility: While we maintain standard dimensions (D1 to D20), our CNC grinding facility specializes in bespoke manufacturing. Specify your exact tolerances, non-standard reaches, and custom laser branding to meet your market's precise needs.
Technical Specifications
| Manufacturer: | Xiaoman Tools (Shanghai, China) |
| Material: | Premium Solid Tungsten Steel (Carbide) |
| Milling Type: | Flat End Mill (General Purpose) |
| Tool Hardness Rating: | HRC50 |
| Performance Coating: | TiAlN (Titanium Aluminum Nitride) |
| Flute Count: | 4 Flutes |
| Dimensions (Dia & Length): | 100% Customizable to OEM Specifications |
| Target Applications: | Stainless Steel, Carbon Steel, Cast Iron, Alloy Steel |
