Industrial HRC60 Long Neck Corner Radius End Mill (Nano Coated) – OEM
Premium 2-Flute Deep Groove Bull Nose Cutter for Hardened Steel (HRC60) – Customizable
Quick Specifications
| Product Name | OEM HRC60 Long Neck Corner Radius End Mill (Nano Coated) |
|---|---|
| Milling Cutter Type | 2-Flute Corner Radius End Mill (Deep Groove / Long Reach) |
| Material | Premium Solid Hard Alloy (Tungsten Steel) |
| Tool Hardness Rating | HRC60 (Engineered for Hardened Mold Steel) |
| Coating | Advanced Nano-Coating (High Thermal & Wear Resistance) |
| Flutes | 2 Flutes |
| Corner Radius (R) | Standard R0.2 - R2.0 (Custom Micro-Radii Supported) |
| Effective Neck Length | Customizable for Deep Cavity Clearances |
| Diameter Range | Standard D1.0 - D20.0mm |
| Application | Deep Cavity Profiling, Mold Steel, Stainless Steel, Carbon Steel |
| Brand Name | Xiaoman Tools |
| Customized Support | 100% OEM/ODM/OBM (Custom Reach, Radii, Laser Etching, Packaging) |
- Factory Direct Pricing
- Strict Standard QC
- Support OEM / Custom Packaging
Want to know the MOQ and latest price?
Product Details
Industrial HRC60 Long Neck Corner Radius End Mill (Nano Coated)
Unmatched Edge Strength and Reach for Deep Cavity Mold Machining
Conquer the most challenging deep-pocket milling operations with Xiaoman Tools' Long Neck Corner Radius End Mills. Designed specifically for the rigorous demands of mold making, these tools feature a strategically relieved neck that prevents shank interference in deep cavities. Furthermore, the precision-ground corner radius (bull nose) reinforces the cutting edge, drastically reducing the risk of chipping when plunging into hardened materials up to 60 HRC. Forged from premium solid tungsten steel and protected by an advanced nano-coating, they deliver exceptional tool life. As a direct source factory, we bypass standard catalog limitations—offering 100% OEM flexibility to customize exact corner radii, specific neck clearances, and private label branding to suit your wholesale network.
Key Technical Advantages
- Long Neck Clearance Design: The reduced neck diameter allows the tool to reach deep into mold cavities, slots, and complex geometries without the shank rubbing against the workpiece walls, preventing vibration and surface damage.
- Reinforced Corner Radius (R-Angle): Unlike sharp square end mills that chip easily in hard metals, the micro-radius corner evenly distributes cutting forces. This immensely strengthens the tip, allowing for aggressive feed rates in hardened steels (up to HRC60).
- Advanced Nano-Coating: Equipped with a high-performance thermal coating that significantly lowers friction and repels heat, preventing thermal shock and edge wear during continuous dry or semi-dry machining.
- Premium Solid Carbide Core: Manufactured from a high-density tungsten steel matrix that provides the ultimate transverse rupture strength required for long-reach tool stability.
- End-to-End OEM Customization: Need a specific R0.2 corner with a 20mm effective reach? We've got you covered. Our advanced CNC grinding facility manufactures bespoke dimensions, geometries, and custom packaging precisely to your clients' blueprints.
Technical Specifications
| Manufacturer: | Xiaoman Tools (Shanghai, China) |
| Material: | Premium Solid Tungsten Steel (Carbide) |
| Milling Type: | Corner Radius End Mill (Long Neck / Bull Nose) |
| Tool Hardness Rating: | HRC60 |
| Performance Coating: | Advanced Nano-Coating |
| Corner Radius (R): | 100% Customizable (e.g., R0.2 to R2.0+) |
| Effective Reach / Dimensions: | 100% Customizable to OEM Specifications |
| Target Applications: | Deep Mold Cavities, Mold Steel, Stainless Steel |
